SECA Usage

Overview

A comprehensive REST API for managing cloud infrastructure resources in compliance with European sovereignty requirements. This API provides control over core Infrastructure-as-a-Service (IaaS) components.

Key Features

• Complete Resource Management: Orchestrate compute instances, block storage, and networking components
• Role-Based Access Control: Integrated RBAC system with fine-grained permissions
• Multi-Tenant Architecture: workspace-based resource organization
• Performance Tiers: Flexible SKUs for compute, storage, and network resources
• RESTful Design: Consistent REST API patterns with standardized responses

Core Services

• Compute: Virtual machine management with various performance tiers
• Storage: Block storage volumes with guaranteed IOPS levels
• Network: Networks, subnets, security groups, and public IP management
• Identity: Integrated authentication and authorization

Technical Specifications

• API Version: v1
• Authentication: JWT-based Bearer tokens
• Content Types: JSON for requests and responses
• Status: Production-ready for core IaaS operations

Current Scope

The API currently focuses on essential IaaS capabilities, providing the fundamental building blocks for cloud infrastructure:

• Compute instance lifecycle management
• Block storage operations with performance guarantees
• Network configuration and security
• Resource organization through workspaces
• Role-based access control

Setting up and Managing Cloud Instances

This guide walks you through the process of creating and managing cloud instances using the Sovereign European Cloud API.

Prerequisites

Authentication

• You need to have an active tenantId from your cloud service provider
• You need a valid JWT token for authentication
• The JWT must contain a sub claim that identifies you (e.g., email or unique identifier)
• Use the token in the Authorization header: Authorization: Bearer <your_jwt_token>
• The tenantId is provided by your iaas cloud provider

SSH Keys

• Prepare your SSH public key
• The system uses external SSH key management
• You'll need the reference to your SSH key for instance creation

Let's suppose you, as subject user@secapi.eu, and tenant administrator, start a new project!

Step 0: Make sure you have the grant to manage a region

Create the Role-Assignment: region-admin-for-user-secapi-eu

PUT ${authorization-provider-url}/v1/tenants/{tenant_id}/role-assignments/region-admin-for-user-secapi-eu
{
  "labels": {}
  "annotations": {
    "description": "Region Administrator for user@secapi.eu"
  },
  "spec": {
    "subs": [
      "user@secapi.eu"
    ],
    "scopes": [
      { "regions": ["europe-country-1"] }
    ]
    "roles": [
      "seca.region-administrator"
    ]
  }
}

Step 1: Get Region Details and Provider References

GET ${region-provider-url}/v1/regions

here you get provider-url, for each resources, that can be:

• dns-based (e.g https://eu-workspace.ionos.secapi.eu)
• path-based (e.g. https://aruba.secapi.eu/providers/seca.workspace)

This will return available regions and their zones. Resources can be created at either the regional level (like Networks and Public IPs) or the zonal level (like Instances).

Step 2: Create a Workspace

Create a workspace to organize your resources:

PUT ${workspace-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod
Content-Type: application/json

{
  "labels": {
    "env": "production",
    "project": "web-shop"
  }
  "annotations": {
    "description": "Production environment for web-shop",
  }
}

Note: Creating a workspace automatically grants you admin permissions for that workspace.

Step 3: Review Available SKUs

Check Compute SKUs

GET ${compute-provider-url}/v1/tenants/{tenant_id}/skus

Available compute tiers:

• seca.ds: 2 vCPU, 4GB RAM, 3000 benchmark points
• seca.dm: 4 vCPU, 8GB RAM, 6000 benchmark points
• seca.dl: 8 vCPU, 16GB RAM, 12000 benchmark points
• seca.sxl: 16 vCPU, 32GB RAM, 24000 benchmark points

Check Storage SKUs

GET ${storage-provider-url}/v1/tenants/{tenant_id}/skus

Important notes about storage:

• Minimum storage size recommended for guaranteed performance depends on the CSP
• Remote Durable Block Storage:
  • seca.rd100: 100 IOPS - Very low-performance remote block storage tier
  • seca.rd500: 500 IOPS - Low-performance remote block storage tier
  • seca.rd2k: 2,000 IOPS - Medium-performance remote block storage tier
  • seca.rd10k: 10,000 IOPS - High-performance remote block storage tier
  • seca.rd20k: 20,000 IOPS - Very high-performance remote block storage tier
• Local Durable Block Storage:
  • seca.ld100: 100 IOPS - Very low-performance local-durable block storage tier
  • seca.ld500: 500 IOPS - Low-performance local-durable block storage tier
  • seca.ld5k: 5,000 IOPS - Medium-performance local-durable block storage tier
  • seca.ld20k: 20,000 IOPS - High-performance local-durable block storage tier
  • seca.ld40k: 40,000 IOPS - Very high-performance local-durable block storage tier
• Local Ephemeral Block Storage:
  • seca.le100: 100 IOPS - Very low-performance local-ephemeral block storage tier
  • seca.le500: 500 IOPS - Low-performance local-ephemeral block storage tier
  • seca.le5k: 5,000 IOPS - Medium-performance local-ephemeral block storage tier
  • seca.le20k: 20,000 IOPS - High-performance local-ephemeral block storage tier
  • seca.le40k: 40,000 IOPS - Very high-performance local-ephemeral block storage tier

Check Network SKUs

GET ${network-provider-url}/v1/tenants/{tenant_id}/skus

Available network tiers:

• seca.n1k: 1000 Mbps guaranteed bandwidth
• seca.n5k: 5000 Mbps guaranteed bandwidth
• seca.n10k: 10000 Mbps guaranteed bandwidth

Step 4: Review Available Images

GET ${storage-provider-url}/v1/tenants/public/images

Available images as an example:

• ubuntu-24.04: Ubuntu 24.04 LTS
• redhat-9.3: Red Hat Enterprise Linux 9.3
• debian-12: Debian 12 (Bookworm)

Step 5: Set Up Storage

Create a block storage volume from an image:

PUT ${storage-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/block-storages/web-shop-os-disk
Content-Type: application/json

{
  "labels": {
    "env": "production",
    "project": "web-shop"
  },
  "annotations": {
    "description": "Linux",
  },
  "spec": {
    "skuRef": "skus/seca.250",
    "sizeGB": 50,
    "sourceImageRef": "tenants/public/images/ubuntu-24.04"
  }
}

Step 6: Set Up Network

6.1 Create a Network

PUT ${network-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/networks/web-shop-network
Content-Type: application/json

{
  "labels": {
    "env": "production",
    "project": "web-shop"
  }
  "annotations": {
    "description": "Production network for web-shop",
  }
  "spec": {
    "skuRef": "skus/seca.n1k",
    "cidr": {
      "ipv4": "10.100.0.0/16"
    }
  }
}

6.2 Create a Subnet

PUT ${network-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/subnets/web-shop-subnet
Content-Type: application/json

{
  "labels": {
    "env": "production",
    "project": "web-shop"
  }
  "annotations": {
    "description": "Public subnet",
  }
  "spec": {
    "networkRef": "networks/web-shop-network",
    "cidr": {
      "ipv4": "10.100.1.0/24"
    }
  }
}

6.3 Set Up Security Group

PUT ${network-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/security-groups/web-shop-sg
Content-Type: application/json

{
  "labels": {
    "env": "production",
    "project": "web-shop"
  },
  "annotations": {
    "description": "Resource with some human readable description",
  },
  "spec": {
    "rules": [
      {
        "annotations": {
          "description": "Allow HTTP(s) from anyone",
        },
        "direction": "ingress",
        "protocol": "tcp",
        "ports": {
          "list": [80, 443]
        },
        "sourceRefs": []
      }
      {
        "annotations": {
          "description": "Allow SSH from secure system",
        },
        "direction": "ingress",
        "protocol": "tcp",
        "ports": {
          "from": 22
        },
        "sourceRefs": [
          "55.44.33.11"
        ]
      }
    ]
  }
}

6.4 Create Public IP

PUT ${network-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/public-ips/ip1
Content-Type: application/json

{
  "spec": {
    "version": "IPv4"
  }
}

Step 7: Create NIC

Create the a NIC with a public IP for the instance (automatically generate the private IPv4):

PUT ${network-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/nics/n1
Content-Type: application/json

{
  "spec": {
    "subnetRef": "subnets/web-shop-subnet",
    "addresses": ["0.0.0.0"],
    "publicIPRef": "public-ips/ip1"
  }
}

Step 8: Create Instance

Create the compute instance:

PUT ${compute-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/instances/web-shop-server
Content-Type: application/json

{
  "labels": {
    "language": "en",
    "billing.cost-center": "platform-eng",
    "env": "production"
  },
  "annotations": {
    "description": "Resource with some human readable description",
    "color": "red",
    "externalID": "980c0d88-09e1-42f9-a4ae-f8f4687d6c99"
  },
  "spec": {
    "skuRef": "skus/gold",
    "primaryNicRef": {
      "provider": "seca.network/v1",
      "resource": "nics/n1"
    }
    "sshKeys": [
      "ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAABAQC0g..."
    ]
    "bootVolume": {
      "deviceRef": {
        "provider": "seca.storage/v1",
        "resource": "block-storages/web-shop-os-disk"
      }
    }
  }
}

Step 9: Access and Use the Instance

1. Wait for the instance to be in "running" state:

   GET ${compute-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/instances/web-shop-server

2. Get the public IP:

   GET ${network-provider-url}/v1/tenants/{tenant_id}/workspaces/web-shop-prod/public-ips/web-shop-ip

3. Connect to your instance:

   ssh -i <your_private_key> ubuntu@<public_ip>

Error Handling

The API uses standard HTTP status codes:

• 400: Bad Request - Check your request format
• 401: Unauthorized - Verify your JWT token
• 403: Forbidden - Check your permissions
• 404: Not Found - Resource doesn't exist
• 412: Precondition Failed - Resource was modified
• 422: Unprocessable Entity - Invalid resource configuration
• 500: Internal Server Error - Contact support

Each error response includes detailed information:

{
  "status": 400,
  "type": "http://secapi.eu/errors/invalid-request",
  "title": "Bad Request",
  "detail": "The request was invalid or cannot be served."
}
